Quickstart Guide

Sensortoolkit allows rapid and reproducible evaluation of air sensor data regardless of data formatting or encoding and facilitates comparison against reference data from a variety of API services or locally maintained data files. Sensor performance is determined using performance metrics and targets recommended by U.S. EPA’s documents on the testing and evaluation of sensors measuring either fine particular matter (PM2.5), PM10, ozone, carbon monoxide, sulfur dioxide, or nitrogen dioxide for use in non-regulatory, supplemental, and informational monitoring applications.

This section walks you through an example scenario, evaluating data from a fictitious air sensor named the ‘Toco Toucan’ against reference data collected from a monitor collocated at the ambient monitoring site where sensors were deployed in triplicate, and a quick summary of how to use sensortoolkit for the first time.

Example Scenario - Toco Toucan

Say that you have chosen to test a sensor from the manufacturer ‘Toco’ called the ‘Toucan’. Three Toco Toucans were deployed at an ambient air monitoring site alongside reference instrumentation. Let’s say that the Toucan air sensor measures both PM2.5 and O3 and that you have confirmed with the agency overseeing the monitoring site that reference-grade monitors designated either Federal Equivalent Methods (FEMs) or Federal Reference Methods (FRMs) are situated at the monitoring site for the pollutants you plan to measure. Following a sampling period of 30 days, you collect data from each Toucan sensor and acquire data from the monitoring agency (AirnowTech) for collocated reference measurements.

1 - Setting Up for sensortoolkit

Setting up for sensortoolkit requires downloading Python and an IDE, creating a project directory, and downloading your sensor and reference data. A brief run through is given below, but more information can be found in the next section.

Download Python and IDE

As sensortoolkit is a Python package, users will need an installation of Python 3.8 or greater. It’s highly recommended that users download Miniconda or Anaconda as both are free installers of a simple open source environment, a package manager, and Python.

Note

Click here for more info about installing Python with Anaconda or Miniconda.

Sensortoolkit works best in development environments that allow you to simultaneously develop scripts, view and explore variables, and execute code. These types of software utilities are called integrated development environments (IDEs). One popular IDE for Python, included alongside Anaconda distributions, is the Spyder IDE. In addition, using a virtual environment is highly recommended for ease of use and to protect the base installation of python.

Create Project Directory

You will need to decide where to store scripts, data, figures, and reports that are related to your current project. This could be any folder location on your computer. I suggest creating a new folder in your documents directory. Let’s call this directory toucan_evaluation.

Example Data Sets

Example data sets for the Toco Toucan sensors and collocated reference monitor are included in the GitHub repository under the /example_datasets folder. Download these files to your project directory.

Note

Click here for more info about setting up for sensortoolkit.

2 - Installing and Updating sensortoolkit

It’s highly recommended to download sensortoolkit into a suitable virtual environment, from the stk_environment.yml file included in the GitHub repository under the /environments folder. Also, sensortoolkit can be easily downloaded with pip, or if you wish to contribute to the development of the package, cloned from the GitHub repository.

Note

Click here for more info about installing sensortoolkit.

Sensortoolkit is actively maintained, and bug fixes and feature enhancements are regularly added to the latest development build. Users are strongly encouraged to update to the latest version of sensortoolkit before using the library for analysis. More information about updating sensortoolkit can be found by following the link below.

Note

Click here for more info about updating sensortoolkit.

3 - Analysis with sensortoolkit

Open up your IDE and create a new python script. You can choose to name this file anything you’d like, but we’ll go with analysis.py for this example. Copy and paste the script template given here.

Follow along the Toco Toucan example outlined in the Analysis with sensortoolkit section to understand the analysis.py script and insert relevant information. Then, this file should be saved in the project directory you created.

Note

Click here for more info about analysis with sensortoolkit and the script template.

4 - Running sensortoolkit

Run the analysis.py script from your IDE and follow the instructions in the console to create and compile a testing report.

For more guidance when following sensortoolkit’s interactive ingestion module, please see the Testing Attribute Objects and Evaluation Objects sections which describe in greater detail importing and working with sensor and reference data while making use of the Toco Toucan example to illustrate how sensortoolkit’s modules work.
